Contex HD Ultra X 4250 Scanner
Description
We designed HD Ultra X to meet the needs of technical experts, graphical professionals, archivists and repro departments. Whether you intend to scan maps, drawings, posters, newspapers or fine art, this scanner will always capture every detail exactly as you see it.
Features:
High-quality lenses
Contex CCD scanners use premium Fujifilm lenses to bring you highresolution images in the best quality available on the market today.
Instant-ON feature
Save valuable time with the ability to start scanning without the warm-up time.
True size detection
HD Ultra X finds the paper width automatically as it scans.
OTAC
Quickly and easily adjust the scanner to the thickness of any original with Optimal thickness adjustment control.
Speed adjustment
Three different speed levels at your fingertips on the touch panel makes it easy to adapt the scanner to your workflow and requirements of the original.
Specifications:
Technology
CCD
Maximum Resolution (interpolated)
9600 dpi
Optical Resolution
1200 dpi
Maximum Scan Width
42 inch (1067 mm)
Maximum Media Width
43.3 inch (1100 mm)
Maximum Media Thickness
0.6 inch (15 mm)
Accuracy
0,1% +/- 1 pixel
Productivity ( Batch scanning Arch E-size, RGB Color, 200dpi for 60 minutes )
866 (documents / hour)
Color Space
Adobe RGB, Device RGB, RAW RGB, sRGB
Software / Nextimage TWAIN
64-bit TWAIN application driver included for use with EDM and other imaging software
Software
WIDEsystem (driver): Nextimage 5 iOS app (portable device) Android tablet/phone OS also
File formats
TIF, JPG, PDF, PDF/A, DWF, CALS, BMP, JPEG-2000(JP2), JPEG2000 Extended(JPX), TIF-G3, TIF-G4, multi-page PDF and others
Touch panel / screen
21.5”-Multi Touch Widescreen, Full HD TFT LCD, 1920×1080 dpi
Weight & Dimensions
49.3 kgs (109 lbs) LxWxH: 1360 mm (53.6’’) x 540 mm (21’’) x 279 mm (11’’)
Operating System
Windows 11 64-bit, Windows 10 32-bit and 64-bit
Energy Star Compliant
Yes
CCD cameras
5 x 4 linear color CCDs (RGB and gray)
Depth of focus
0.3 inches (7 mm)
Total number of pixels
213600 pixels
Country of origin
Designed and engineered in Denmark, manufactured in China
Upgradable color speed
Yes
200 dpi grayscale/monochrome
17.8
Certifications/ Energy Star Compliant
RoHS, REACH, cUL, CE, Customs Union, CCC, VCCI, ENERGY STAR® certified
Scan speed (200 dpi RGB color)
8.9 ips
Connectivity
USB 3.0 with xDTR3, Gigabit Ethernet with xDTR2.5
Scanner stand (optional)
36.3 / 37.3 / 38.3 inches (922 / 947 / 972 mm)
